corner styled split winch

Price: 10.0 USD
Payment Terms: T/T,L/C
Place of Origin: Jiangsu, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Means of Transport: Ocean,Air
Packing: wooden case
Production Capacity: 20set/month
Delivery Date: 7days

corner styled split winch
Working load:8~12KN
Supporting load:24-36KN
Rope Dia.:9~12mm

Mainly used for handling accommodation ladders upon the berthing of the vessel as well as handling the pilot ladders when the vessels enter the harbor.The axis of the motor and the reeling drum are laid out perpendicularly.

  Electric winch

Working load

8~12KN

13~16KN

Supporting load

24~36KN

39~48KN

Rope Dia

Φ9~12mm

Φ13~15mm

Electric motor

380v,50hz

3.7kw

380v,50hz

5.5KW

440v,60hz

4.0kw

440v,60hz

6.3KW

Duty factor

30min

Hoisting speed

5~10m/min

Pneumatic winch

Working load

8~12KN

13~16KN

Support load

24~36KN

39~48KN

Rope Dia

Φ9-12mm

Φ13~15mm

Pneumatic motor

Power

3.5~5.5ps

7ps

Air consumption

3.5~5.5m3/min

7m3/min

Air press

0.5~0.7Mpa

Hoisting speed

3.5~10m/min
